Temperature Probes - Rotronic RMS T10-XXXX
特点
- NTC sensor
- No influence from the lead
- High temperature sensitivity
The T10 temperature sensors are NTC (Negative Temperature Coefficient) thermistors, meaning that the resistance of the NTC decreases with increasing temperature. The T10 temperature sensors are compatible with the RMS-MLOG-T10-868/915 data loggers.
The data logger temperature range is limited to -35…80°C. The RMS temperature portfolio covers a wide range of applications, from the coldest such as liquid nitrogen tanks and cryogenic freezers, refrigerators and cold rooms to hotter ones such as water baths, incubators, ovens and autoclaves.
Please see below for the values of each probe. This list is not exhaustive and other probes, diameters and cable lengths are available on request:
| T10-0001 | T10-0002 | T10-0003/0013/0113 | T10-0004 | T10-0005 | T10-0006 | |
|---|---|---|---|---|---|---|
| Cable Material | PTFE | Silicone | Silicone | Silicone | PTFE | Silicone |
| Sensor Application Range | -196...-90 °C | -80...150 °C | -50...120 °C | -50...120 °C | -90...50 °C | -80...150 °C |
| Cable Application Range | -190…260 °C | -50…200 °C | -50…200 °C | -50…200 °C | -190…260 °C | -50…200 °C |
| IP Protection | IP65 | IP65 | IP65 | IP65 | IP68 | IP65 |
| Cable Length | 2000 | 4000 | 2000 | 2000 | 40000 | 4000 |
| Cable Diameter (mm) | 4 | 6 | 6 | 6 | 4 | 6 |
| Probe Head Material | SS 316 | VA4 1.4571 | VA4 1.4571 | Brass | VA4 1.4571t | VA4 1.4571 |
| Probe length (mm) | 50 | 50 | 50 | 50 | 50 | 50 |
| Probe Diameter (mm) | 6 - 6.15 | 6 - 6.15 | 6 - 6.15 | Duct wrap | 6 - 6.15 | 6 - 6.15 |
| Sensor | NTC1k | NTC10K | NTC10K | NTC10K | NTC1K | NTC10K |
